Leibinger JET2neo - Drawings; Print Head

Group 12 Appendix Page 279
JET2 neo Release R1.12 en
12.3 Drawings
12.3.1 Print head
1 Nozzle
4 Drain tube
2 Charging electrode
5 HV deflection plates
3 Detector electrode
6 Oscillator
 43 mm
212 mm
6
5
3
1
2
4
