Leibinger JET2neo - Figure 96 - Piezo Test and Charge Test; Figure 97 Detector Test

Page 162 Data entry/Programming Group 7
Release R1.12 en JET2 neo
Figure 96
Piezo test and charge test
1 – Button <Piezo test>
3 – Message <Piezo test>
2 – Button < Charge test>
4 – Message <Charge test>
6. Detector test
With the button <Detector test> (1) you can start the test.
Figure 97
Detector test
1 – Button <Detector test>
3 – Button <Stop>
2 – Message <Detector test>
1
2
3
1
2
3
4
