Leibinger JET2neo - Interfaces; Figure 11 Interfaces

Group 5 Transport/Start up Page 43
JET2 neo Release R1.12 en
5.5 Interfaces
The following interfaces are available on the rear side of the electronics cabinet.
Figure 11
Interfaces
1 – Electronic cabinet
5 – Interface X4 – digital inputs
2 – Interface X1 – Encoder
6 – Network connection RJ 45
3 – Interface X5 – PrintGo
7 – USB connection
4 – Interface X3 – digital outputs
5
2
3
7
4
6
1
