Page 58 Operation – Elements and procedures Group 6
Release R1.12 en JET2 neo
Figure 17
Status field <Product counter>
You will find further information also in the chapters Reset production
counter and Change production counter as well as in the chapter Pre-
defined print stop!
 Status field <Nozzle> (8): This field enables the opening or closing of the nozzle and
shows additional the current operating condition of the nozzle by an active visualization
graphic.
Figure 18
Status field <Nozzle>
1 – Button <Opening nozzle>
3 – Visualization field
2 – Button <Closing nozzle>
With the buttons <Opening nozzle> (1) and <Closing nozzle> (2) you can open or close
the nozzle. The executable button is backgrounded blue-grey.
1
2
3
3
