Leibinger JET2neo - Figure 145 - Extern Text:interface Settings

Group 8 Job editor Page 239
JET2 neo Release R1.12 en
Figure 145
Extern Text: Interface settings
1 – Menu item <Interface settings>
8 – Display field <Port> Number
2 – Dialog box <Interface settings>
9 – Plus/Minus buttons <Port> number
3 – Drop-down list <Connection type>
10 – Numeric keypad
4 – Selected <Connection type>
11 – Button <OK>
5 – <Connection> - <Port number>
12 – Button <Cancel>
6 – Selected <Connection type>
13 – Tab <IP-Address>
7 – <Connection> - <Port number>
14 – <IP-Address> settings
