Group 7 Data entry/Programming Page 97
JET2 neo Release R1.12 en
Figure 45
Graphic editor (Delete graphic elements)
1 – Drawing tool <Selection>
6 – Edit tool <Delete>
2 – Start point (catch frame)
7 – Drawing tool <Selection>
3 – Display <Coordinates>
8 – Start point (catch frame)
4 – Display <Activities to carry out>
9 – End point (catch frame)
5 – End point (catch frame)
10 – Edit tool <Delete>
3
4
1
2
5
Areas
(elements)
to delete
6
7
8
9
10
