8.5.3.3 Rotating direction
(Encoder direction)
With the setting you can select the rotating direction of the encoder.
 Rotating direction right (clockwise): If this control box is activated, the encoder has
to turn right for printing.
 Rotating direction left (counter clockwise): If this control box is activated the
encoder has to turn left for printing.
 Rotating direction both: If this control box is activated it is printed if the encoder turns
left or right.
Note: Encoder signals are only analyzed for correct set rotating direction.
8.5.3.4 Resolution
The setting determines the encoder resolution that means it defines how many impulses
are generated by the encoder per set measurement. The input happens in the unit
Pulse/mm.
The set value is shown on the accordant display field.
Example:
An encoder which generates 10.000 impulses/rotation with a friction wheel
and which has a circumference of 200 mm is used.
Calculation: Resolution= Impulses/Rotation:
Circumference
= 10.000: 200 = 50 (Pulses/mm)
