Example of error:
8.5.2.1.3 PrintGo-repetitions
The setting defines the amount of text outputs (print repetitions) by the set value between
the several text outputs. Values between 0 – 1000 are permitted.
Example
:
0 = no repetition (single print)
1 = one repetition (double print)
The set value is shown on the accordant display field.
To get an endless repetition of the print outputs, you have to activate the control box
<endless> (2).
Figure 122
PrintGo-repetitions
1 – Display field <PrintGo repeat>
3 – Control box <endless> active
2 – Control box <endless> deactive
Print-Go distance
too small
Print-Go distance
correct
2
1
3
