Leibinger JET2neo - Contrast Value; Figure 109 - Object Settings (Contrast)

Page 180 Job editor Group 8
Release R1.12 en JET2 neo
8.4.2 Contrast value
The setting determines the print contrast of the object. The value can be set between 0 –
7.
To get a contrast increasing of the print out, you have to place several dots on top of each
other (on the same position).
Example
0 = no contrast increasing (single print out)
1 = 2 dots are placed on top of each other
2 = 3 dots are placed on top of each other
…..
7 = 8 dots are placed on top of each other
The set value is shown on the accordant display field.
Figure 109
Contrast
Display: normal
with contrast
Attention! From the technical side the function <Contrast> can only
used for complete strokes (vertical dot line). This means that all further
strokes which are placed above or below the attribute setting are also
generated with the contrast additionally to the affected object.
Example:
For a double-spaced font only the lower line is reserved with the
attribute „Contrast“. The elements of the first line which are placed
above the attribute setting will be also printed automatically with the
attribute “Contrast”.
As higher the contrast has been set, as lower is the max. printing speed!
Contrast area
Leibinger Ink-Jet
Printer
