Leibinger JET2neo - Figure 126 - Printgo-Gate;Print Start Query; Printgo-Gate

Group 8 Job editor Page 199
JET2 neo Release R1.12 en
8.5.2.2.2 PrintGo-Gate
(Print start query)
A further print start query option is available with this function. If the function is activated
the print process happens only as long as the enquired sensor is active.
The sensor which is required for the PG-gate has to be connected to the interface X5 of
the LEIBINGER JET2neo also.
Example: Endless print of tubes with interruptions between the end of the previous tube
and the beginning of the following tube.
Figure 126
PrintGo-Gate (Print start query)
Activating options:
 HighLevel active:
 LowLevel active:
