Group 8 Job editor Page 243
JET2 neo Release R1.12 en
1 – Direct button <Extern Text>
10 – Selection <Mailing>
2 – Dialog box <Object settings>
11 – Checkbox <Double Prints>
3 – Tab <Global settings.>
12 – <Wildcard> settings
4 – Font settings
13 – <Offset> indicator/settings
5 – Font options
14 – Indicator/input <Wildcards> Number
6 – Position indicator/-settings
15 – Indicator/input <Wildcards> Content
7 – Tab <Extern Text>
16 – Numeric keypad for (13) und (14)
8 – Drop-down list <Type>
17 – Keyboard for (15)
9 – Selection <Extern Text>
18 – Extern Text Object in the job editor
8.6.6.1.3 Extern Text: Print out/Deleting the input buffer
There can be up to 32 <Extern Text> objects within a print job. For each object you can
define the number of wildcards and the offset separately.
But nevertheless all <Extern Text> objects within a print job will process the same
received character string. It is just a matter of the wildcard and the offset settings which
part of the received character string is used by the
<Extern Text: Fixed length> object.
The received serial data are stored in an input buffer. The size of this buffer is defined
the <Extern Text> object that have the largest sum from wildcards and offset.
If you like to use more than one <Extern Text> object in a print job it is mandatory
that the transferred string is always of the same length.
Example print-out:
This example is based on a print job with three <Extern Text> objects.
Each object has different settings for wildcards and offset (abbreviated: OS).
The character string 12ab345 shall be transmitted. The settings for each
<Extern Text> object look as follows:
