Page 94 Data entry/Programming Group 7
Release R1.12 en JET2 neo
1. Save an open existing graphic:
Press the button <Save> (1) in the menu bar of the editor. The graphic will be saved
under the existing filename.
2. Save a newly created graphic:
Press the button <Save> (1) in the menu bar of the editor.
The window <Save Graphic> (2) is faded in.
The names of the already existing graphics are displayed in the selection field
<Graphic list> (3). With the pop-up window <Search in> (4) you can select the
different memory locations.
Click in the display <Filename> (5). A keyboard field (6) opens for input.
You will find further information regarding the working with
keyboard fields in the chapter Keyboard fields (page (62)!
Enter the requested name.
Press the button <Return > (7) of the keyboard field. The entered name will be
taken over to the display <Filename> (5).
Press the button <OK ()> (9) to finish the storage process or press the button
<Cancel> (8) to cancel the process.
