Service
Tables
SERVICE PROGRAM MODE TABLES
SM 5-49 B079/B082
SP5 Mode Number Function and [Setting]
76* Magnification for Printer
B&W HQ
Sets the default magnification for stored printer
black and white documents sent to the document
management server via the MLB with higher quality
given priority.
[0~3 / 2 / 1]
0: 1-to-1
1: 1/2
2: 1/4
3: 1/8
Enabled only when optional MLB (Media Link
Board) is installed.
81* Format for Copy Color Sets the default format for stored copy color
documents sent to the document management
server via the MLB.
[0~3 / 0 / 1]
0: JFIF/JPEG
1: TIFF/MMR
2: TIFF/MH
3: TIFF/MR
Enabled only when optional MLB (Media Link
Board) is installed.
82* Format for Copy B&W Text Sets the default format for stored copy black and
white text documents sent to the document
management server via the MLB.
[0~3 / 1 / 1]
0: JFIF/JPEG
1: TIFF/MMR
2: TIFF/MH
3: TIFF/MR
Enabled only when optional MLB (Media Link
Board) is installed.
83* Format Copy B&W Other Sets the default format for stored other than black
and white documents sent to the document
management server via the MLB.
[0~3 / 1 / 1]
0: JFIF/JPEG
1: TIFF/MMR
2: TIFF/MH
3: TIFF/MR
Enabled only when optional MLB (Media Link
Board) is installed.
5836
84* Format for Printer Color Sets the default format for stored printer color
documents sent to the document management
server via the MLB.
[0~3 / 0 / 1]
0: JFIF/JPEG
1: TIFF/MMR
2: TIFF/MH
3: TIFF/MR
Enabled only when optional MLB (Media Link
Board) is installed
