SERVICE PROGRAM MODE TABLES
B079/B082 5-66 SM
SP7 Mode Number Function and [Setting]
13* Duplex Exit 2: On
14* Duplex Exit 3: On
16* Exit 1 Off
17* Bridge Unit – 1 Off
18* Bridge Unit – 2 Off
19* Ent Duplex 1 Off
23* Exit Duplex Off
24* 1-Bin Tray (Check-In Error)
25* Finisher Entrance
26* Finisher Proof Tray
27* Finisher Shift Tray
28* Finisher Stapler
29* Finisher Exit
30* Mailbox Entrance
31* Mailbox Proof Tray
32* Mailbox Relay
33* Mailbox MBX
35* Booklet Fin Entrance
36* Booklet Fin Transport
37* Booklet Fin Early
38* Booklet Fin Staple
39* Booklet Fin Late Staple Stitch
40* Ent. Fin. Off
41* Exit – Fin. Off
57* LCT Tray
58* Vert. Trans 1: On
59* Vert. Trans 2: On
60* Bank 1 On
62* Registration: Off
63* External Tray: Off
66* Duplex Exit 1: Off
67* Duplex Exit 2: Off
68* Duplex Exit 3: Off
69* Duplex Feed: Off
73* Exit Duplex On
7504*
74* 1-Bin Tray (Check-Out Error)
Total Original Jam by Location Displays the total number of original jams by
location. These jams occur when the original
does not activate the sensors.
A “Paper Late” error occurs when the paper fails
to activate the sensor at the precise time. A
“Paper Linger” paper jam occurs when the paper
remains at the sensor for longer than the
prescribed time.
1*
At Power On
Paper Late
Error No.
Paper Lag
Error No.
Error Location
3 53 Registration Sensor Check In Failure
7505*
4 54 Nip-In Sensor Check In Failure
