SERVICE PROGRAM MODE TABLES
SM 5-67 B079/B082
SP7 Mode Number Function and [Setting]
5 55 Registration Sensor (On Check)
6 56 Relay Sensor (On Check)
7505*
7 57 Inverter Sensor (On Check)
Jam Count by Copy Size
5* A4 LEF
6* A5 LEF
14* B5 LEF
38* LT LEF
44* HLT LEF
132* A3 SEF
7506*
133* A4 SEF
Displays the total number of copy jams by paper
size.
134* A5 SEF
141* B4 SEF
142* B5 SEF
160* DLT SEF
164* LG SEF
166* LT SEF
172* HLT SEF
7506*
255* Others
Displays the total number of copy jams by paper
size.
Copy Jam History (Transfer
Sheet)
1* Last
2* Last 1
3* Last 2
4* Last 3
5* Last 4
6* Last 5
7* Last 6
8* Last 7
9* Last 8
10* Last 9
Displays the copy jam history of the transfer unit
in groups of 10, starting with the most recent 10
jams.
Sample Display:
CODE: 007
SIZE: 05h
TOTAL: 0000334
DATE: Mon Mar 15 11:44:50 2000
where:
CODE is the SP7-505-*** number (see above.
SIZE is the paper size code in hex.
TOTAL is the total jam error count (SP7-003)
DATE is the date the previous jamLEF occurred.
Paper Size Code (hex)
A4 LEF 05
A5 LEF 06
B5 LEF 0E
LT LEF 26
HLT LEF 2C
A3 SEF 84
A4 SEF 85
A5 SEF 86
B4 SEF 8D
B5 SEF 8E
DLT SEF A0
LG SEF A4
LT SEF A6
HLT SEF AC
7507*
Others FF
