SERVICE PROGRAM MODE TABLES
B079/B082 5-68 SM
SP7 Mode Number Function and [Setting]
Original Jam History
1* Last
2* Last 1
3* Last 2
4* Last 3
5* Last 4
6* Last 5
7* Last 6
8* Last 7
9* Last 8
7508*
10* Last 9
Displays the original jam history in groups of 10,
starting with the most recent 10 jams.
Sample Display:
CODE: 007
SIZE: 05h
TOTAL: 0000334
DATE: Mon Mar 15 11:44:50 2000
where:
CODE is the SP7-505-*** number (see above.
SIZE is the paper size code in hex.
TOTAL is the total error count (SP7-003-001)
DATE is the date the previous jamLEF occurred.
7801 ROM No./Firmware Version Displays the ROM number and firmware version
numbers.
7803* PM Counter Display Displays the PM counter since the last PM.
7804 PM Counter Reset
Resets the PM counter. To reset, press .
7807 SC/Jam Counter Reset Resets the SC and jam counters. To reset, press
.
This SP does not reset the jam history counters:
SP7-507, SP7-508.
7808 Counter Reset Resets all counters except SP7-003-***, SP7-
006-***. To reset, press .
7810 Access Code Clear Use to clear the access code if the customer
forgets the code. After clearing the code is reset
for Null and the password entry display does not
open. To clear, press .
7811 Original Count Clear Clears the original total display, displayed with
SP7-002-***. To clear, press .
Print Counter Reset
1 Tray1
2 Tray2
3 Tray3
4 Tray4
5 LCT
7816
6 By-pass
Resets the total copy count by paper tray. To
reset, press .
Use these SP modes when replacing the pick-
up, feed, and separation rollers.
7822 Copy Counter Reset
Magnification
Resets all counters of SP7-301 (Copy Count:
Magnification).
7825 Total Counter Reset No longer used. Executing this SP has no effect.
This SP is no longer required because the
counter initialized (set to “0”) at the factory.
7826* MF Device Error Count This display is for the Japanese version only.
Japan Only
7827 MF Device Error Count Clear This SP is for the Japanese version only. (Clears
SP7-826.) Japan Only
7832 Self-Diagnosis Result Display Execute to open the “Self-Diagnose Result
Display” to view details about errors. Use the
keys on in the display on the touch-panel to
scroll through all the information. If no errors
have occurred, you will see the “No Error”
notation.
To Next Page
