SERVICE PROGRAM MODE TABLES
SM 5-73 B079/B082
Reading
Number Bit Description
0 1
7 Duplex reverse path door Closed Open
6 Paper End Sensor Paper detected Paper not detected
5 Not used
4 Paper Size Sensor 4, By-pass Activated Deactivated
3 Paper Size Sensor 3, By-pass Activated Deactivated
2 Paper Size Sensor 2, By-pass Activated Deactivated
1 Paper Size Sensor 1, By-pass Activated Deactivated
4: By-pass
Feed
0 Unit Set Signal Yes No
7 Not used Yes No
6 Unit Set Signal Connected Not connected
5 Paper Sensor Paper detected Paper not detected
4 Relay Sensor Paper detected Paper not detected
3 Exit Sensor Paper detected Paper not detected
2 Left Cover Switch Switch pressed
(cover closed)
Switch not pressed
1 Middle Cover Switch Switch pressed
(cover closed)
Switch not pressed
5: Relay Unit
(Bridge Unit)
0 Right Cover Switch Switch pressed
(cover closed)
Switch not pressed
7 Feed Motor Lock No Yes
6 F-Gate Signal Active Not active
5 Height Sensor Feed height Not feed height
4 Paper Exit Sensor Paper detected Paper not detected
3 Fusing Unit Detected Not detected
2 Total Counter Not detected Detected
1 Key Counter Detected Not detected
6: Unit Set
0 Key Card Present Detected Not detected
7 Front cover/open closed Open Closed
6 Vertical feed path Clear Not clear
5 2nd Tray Height Sensor Paper not at upper
limit
Paper at upper limit
4 1st Tray Height Sensor Paper not at upper
limit
Paper at upper limit
3 Lower Relay Sensor Paper detected Paper not detected
2 Upper Relay Sensor Paper detected Paper not detected
1 Lower Paper End Sensor Paper not detected Paper detected
7: Paper End
0 Upper Paper End Sensor Paper not detected Paper detected
