Ricoh B079 - Page 300

SERVICE PROGRAM MODE TABLES
B079/B082 5-74 SM
Reading
Number Bit Description
0 1
7 Dip Switch - 8 On Off
6 Dip Switch - 7 On Off
5 Dip Switch - 6 On Off
4 Dip Switch - 5 On Off
3 Dip Switch - 4 On Off
2 Dip Switch - 3 On Off
1 Dip Switch - 2 On Off
8: DIP
Switches
0 Dip Switch - 1 On Off
7 Not used
6 Right cover open/closed Closed Open
5 1-Bin Unit Set Detected Not detected
4 LD, HP sensor Positioned Not positioned
3 Exit Sensor (Jam) Paper detected Paper not detected
2 Entrance Sensor (Jam) Paper detected Paper not detected
1 Paper End Sensor Paper detected Paper not detected
9: Duplex Unit
0 Duplex Unit Switch Cover closed Cover open
7 Tray 4: Bit 1
8 Tray 4: Bit 0
Bit 1 Bit 0 Capacity
5 Tray 3: Bit 1 1 1 Full
4 Tray 3: Bit 0 1 0 50% or more
3 Tray 2: Bit 1 0 1 10% or more
2 Tray 2: Bit 0 0 0 Out, or tray not set
1 Tray 1: Bit 1
10:
Remainder of
Feed Tray 1
0 Tray 1: Bit 0
7 By-pass Yes/No
6 Not Used
5 Not Used
4 Not Used
3 Not Used
Bit 2 Bit 1 Bit 0 Capacity
2 LCT: Bit 2 1 1 1 Full
1 LCT: Bit 1 1 0 0 80% or more
11:
Remainder of
Feed Tray 2
0 LCT: Bit 0 0 1 1 50% or more
0 1 0 30% or more
0 0 0 10% or more
