Ricoh B079 - Page 301

Service
Tables
SERVICE PROGRAM MODE TABLES
SM 5-75 B079/B082
Reading
Number Bit Description
0 1
7 Mailbox 9-bin Not full or no tray Full
6 Mailbox 8-bin Not full or no tray Full
5 Not used - -
4 Finisher: Shift Tray 1 Not full or no tray Full
3 Finisher: Shift Tray 2 Not full or no tray Full
2 Not used - -
1 1-Bin Exit Not full or no tray Full
12: Full Exit
Tray 1
0 Machine Exit Not full or no tray Full
7 Mailbox 7-bin Not full or no tray Full
6 Mailbox 6-bin Not full or no tray Full
5 Mailbox 5-bin Not full or no tray Full
4 Mailbox 4-bin Not full or no tray Full
3 Mailbox 3-bin Not full or no tray Full
2 Mailbox 2-bin Not full or no tray Full
1 Mailbox 1-bin Not full or no tray Full
13: Full Exit
Tray 2
0 Mailbox Proof Tray Not full or no tray Full
Table 1: By-pass Feed Table Paper Size Data
Number. Bit 4 Bit 3 Bit 2 Bit 1 Paper Width
4: By-pass 1 1 1 1 Post Card
1 1 1 0 B6 SEF
1 1 0 1 B5 SEF
1 1 0 0 A5 SEF / 5.5"
1 0 1 1 B4 SEF
1 0 0 1 A4 SEF / 8.5" / 8"
0 1 1 1 A3 SEF
0 0 1 1 11" x 17"
