MAIN MACHINE INSTALLATION
B079/B082 1-10 SM
7. Spread a large piece of paper on a flat surface.
NOTE: Make sure the area is free of pins, paper clips, staples, etc. to avoid
attraction to the magnetic development roller.
8. Slide the development unit [A] out and place it on the paper.
9. Remove the tape and tag [B] from the development unit
10. Remove the entrance seal plate [C] ( x 2).
B079I512.WMF
B079I105.WMF
[A]
[B]
[C]
To Next Page
