REMOVAL
SM 31 B546
Booklet
Finisher
B546
6. Remove the jogger plates [A] ( x 1 ea.).
7. Slide the folder rollers [B] to the front and remove them.
B546R599.PCX
B546R549.PC
X
[A]
[B]
