SP2-XXX (Drum) -1
SM Appendices
3-51 D0CA/D0C9/D0C8/D0CB
Appendices
SP Mode Tables
SP No. Large Category Small Category ENG
or
CTL
[Min to
Max/Init./Step]
2 * 16.00 / -0.62 /
0.01dot/step]
2-150-08
3
Area Mag. Correction Area 4: Ma ENG
*
[-16.00 to
16.00 / -0.40 /
0.01dot/step]
2-150-08
4
Area Mag. Correction Area 5: Ma ENG
*
[-16.00 to
16.00 / 0.00 /
0.01dot/step]
2-150-08
5
Area Mag. Correction Area 6: Ma ENG
*
[-16.00 to
16.00 / 0.39 /
0.01dot/step]
2-150-08
6
Area Mag. Correction Area 7: Ma ENG
*
[-16.00 to
16.00 / 0.56 /
0.01dot/step]
2-150-08
7
Area Mag. Correction Area 8: Ma ENG
*
[-16.00 to
16.00 / 0.31 /
0.01dot/step]
2-150-13
1
Area Mag. Correction Area 0: Cy ENG
*
[-16.00 to
16.00 / 0.00 /
0.01dot/step]
2-150-13
2
Area Mag. Correction Area 1: Cy ENG
*
[-16.00 to
16.00 / 0.18 /
0.01dot/step]
2-150-13
3
Area Mag. Correction Area 2: Cy ENG
*
[-16.00 to
16.00 / 0.49 /
0.01dot/step]
2-150-13
4
Area Mag. Correction Area 3: Cy ENG
*
[-16.00 to
16.00 / 0.42 /
0.01dot/step]
2-150-13
5
Area Mag. Correction Area 4: Cy ENG
*
[-16.00 to
16.00 / 0.11 /
0.01dot/step]
2-150-13
6
Area Mag. Correction Area 5: Cy ENG
*
[-16.00 to
16.00 / -0.26 /
0.01dot/step]
2-150-13 Area Mag. Correction Area 6: Cy ENG [-16.00 to
