Input and Output Check
D0CA/D0C9/D0C8/D0CB 3-456 SM Appendices
No. Part Name SP Name SP No. Remark
FC Drum
Motor: Low
Speed
5-804-028 Before the restoration operation of the
machine after abnormal stop, for example
JAM, if the drum motor (CMY) (M10) is
turned ON with these SPs, only the color
drums drive. At this time, the ITB has
stopped but the ITB is in contact with the
color drums. Therefore the color drums and
the ITB may be damaged.
FC Drum
Motor: Middle
Speed
5-804-095
5 Drum motor
(M11)
Bk Drum
Motor: Std
Speed 1
5-804-022 When you turn ON the motor with these
SPs, make sure to separate the color drums
and ITB.
Before the restoration operation of the
machine after abnormal stop, for example
JAM, if the drum motor (K) (M11) is turned
ON with these SPs, the K drum and ITB
drive. At this time, the color drums have
stopped but the color drums are in contact
with the ITB. Therefore the color drums and
the ITB may be damaged.
In addition, if turn ON for a long time, the
cleaning blade can be distorted. When you
keeps ON with the ITB unit installed, make
sure to do it within 10 seconds.
Bk Drum
Motor: Low
Speed
5-804-023
Bk Drum
Motor:
Standard
Speed 2
5-804-090
Bk Drum
Motor: Middle
Speed
5-804-093
6 Development
Clutch
(K) (CL5)
Development
Clutch: Bk
5-804-026
