FCU (PCB2)
SM 19 D0CK
• If the beeper does not sound after turning the main switch on and off 3 times, you need to
input the settings stored in SRAM memory manually.
14. When “Ready” appears on the operation panel display, turn OFF the main power, and then
disconnect the FFC from the old FCU (PCB2) board.
15. Disconnect the FFC from the new FCU (PCB2) board.
16. Reassemble the machine.
17. Turn ON the main power. Execute SP6-101 to print the system parameter list.
18. Check the system parameter list to make sure that the data is transferred correctly.
19. Set the correct date and time with the System settings.
"Settings" icon > [System settings] > [Date/Time/Timer].
