Bit Switches – 5
SM 97 D0CK
Bit 5 Bit 4 data transmission and T.38 phase decision. If your destination return is
late on the network or G3 fax return is late, adjust the longer interval
timer.
The default is "00" (75 seconds).
0 0 75s
0 1 120s
1 0 180s
1 1 240s
6-7 Not used Do not change these settings.
IP Fax Switch 09 (SP No. 1-111-010)
No. Function Comments
0 Network I/F setting for SIP
connection
0: IPv4
1: IPv6.
Selects the connection type (IPV4 or IPV6) to connect to the
SIP server.
1 Network I/F setting for Fax
communication
0: Same setting as SIP server
connection
1: Automatic setting
0: The I/F setting for fax communication follows the setting
for SIP server connection.
1: The negotiation between the SIP server and the device
decides whether IPv4 or IPv6 is used for the I/F setting for
fax communication.
2 Record-route setting
0: Disable
1: Enable
0: Disables the record-route function of the SIP server.
1: Enables the record-route function of the SIP server.
3-4 re-INVITE transmission delay
timer setting
This changes the interval for transmit re-INVITE after
receiving the ACK message transmitted by T.38 device.
Bit 4 Bit 3
0 0 No delay
0 1 1 sec
1 0 2 sec
1 1 3 sec
5 SIP-IPFAX: Adding vender
information selection
0: Declare
T38VendorInfo=RICOH
1: Not declare
T38VendorInfo=RICOH
0: Use this setting normally.
1: This setting is used only when a customer wants to
connect the machine with SIP server + VOIP-GW provided
by AVAYA Inc.
6-7 Not used. Do not change these settings.
IP Fax Switch 0A - Not used (do not change the settings)
IP Fax Switch 0B - Not used (do not change the settings)
