Ricoh IM C300

Image/Paper Transfer
D0CA/D0C9/D0C8/D0CB 4-128 SM
• Fusing Motor (M13)
• Paper Transport Motor (M12)
• Drive Unit
2. Remove the ITB lift unit [A].
3. Remove the ITB lift HP sensor (S33) with the bracket [A].
4. Remove the ITB lift HP sensor (S33) [A]. (Hook × 2)
