Machine Overview
D0CA/D0C9/D0C8/D0CB 7-6 SM
IM C400SRF
Callout Item Callout Item
[A] ADF transport path [E] Optional paper feed unit path (1st)
[B] 1-Bin tray path*1 [F] Optional paper feed unit path (2nd)
[C] Duplex paper transport path [G] Standard paper tray path
[D] Bypass paper feed path [H] Optional paper feed unit path (3rd)
*1 IM C 300 series/C400F are optional. IM C400SRF is not supported.
