Machine Overview
D0CA/D0C9/D0C8/D0CB 7-16 SM
Callout Item Callout Item
1 Fusing Thermostat 6 Pressure Roller Thermistor (Edge:
front) (TH2)
2 Fusing Heater 7 Fusing Exit Sensor (S8)
3 Fusing Thermistor (Non-contact
Sensor) (S10)
8 Fusing Entrance Sensor (S3)
4 Pressure Roller Thermistor (Edge:
rear) (TH3)
9 Fusing Thermopile (TH1)
5 Pressure Roller Thermistor (Edge:
center) (TH4)
- -
