Ricoh IM C300

Scanner Unit
D0CA/D0C9/D0C8/D0CB 7-30 SM
Callout Item Callout Item
[A] LED array board (LEDB) [G] 4th mirror
[B] Light guiding panel [H] 5th mirror
[C] Reflectors [I] Lens
[D] 1st mirror [J] CCD
[E] 2nd mirror [K] Light Path
[F] 3rd mirror - -
