Remote control commands
R&S
®
RTP
1195User Manual 1337.9952.02 ─ 12
ACQuire:MUWaveform <MultiWaveform>
For each channel, up to three waveforms can be shown and analyzed. The decimation
mode and the waveform arithmetic are specific for each waveform. So you can analyze
several aspects of the signal: For example, waveform1 shows the peaks, and wave-
form2 shows the average of the signal.
Parameters:
<MultiWaveform> ON | OFF
*RST: OFF
Usage: Asynchronous command
Firmware/software: FW 3.20
CHANnel<m>[:WAVeform<n>][:STATe]
<State>
Activates or deactivates a waveform. [:STATe] can be omitted.
Up to 3 waveforms per channel can be analyzed.
Suffix:
<m>
.
1..4
Selects the input channel.
<n> 1..3
Selects the waveform. If [:WAVeform<n>] is omitted, waveform 1
is adressed.
Parameters:
<State> ON | OFF
*RST: OFF
Example:
CHAN2:WAV2 ON
Activates waveform 2 of channel 2 (C2W2).
Usage: Asynchronous command
CHANnel<m>[:WAVeform<n>]:TYPE <DecimationMode>
Selects the method to reduce the data stream of the ADC to a stream of waveform
points with lower sample rate.
See also:"Mode" on page 151.
Suffix:
<m>
.
1..4
Selects the input channel.
<n> 1..3
Selects the waveform. If [:WAVeform<n>] is omitted, waveform 1
is adressed.
Parameters:
<DecimationMode> SAMPle | PDETect | HRESolution | RMS
