22.19.3 Output setup
WGENerator<m>:OUTPut[:LOAD]................................................................................. 2235
WGENerator<m>:VOLTage[:VPP]..................................................................................2235
WGENerator<m>:VOLTage:DCLevel..............................................................................2235
WGENerator<m>:VOLTage:HIGH..................................................................................2236
WGENerator<m>:VOLTage:INVersion............................................................................ 2236
WGENerator<m>:VOLTage:LOW...................................................................................2236
WGENerator<m>:VOLTage:OFFSet...............................................................................2236
WGENerator<m>:OUTPut[:LOAD] <Load>
Sets the load of the DUT at its connection.
Suffix:
<m>
.
1..2
Parameters:
<Load> FIFTy | HIZ
HIZ: high input impedance
*RST: HIZ
WGENerator<m>:VOLTage[:VPP] <Amplitude>
Sets the amplitude, peak to peak voltage, of the output waveform. This is defined as
the voltage difference between the maximum (WGENerator<m>:VOLTage:HIGH) and
the minimum (WGENerator<m>:VOLTage:LOW) voltage levels.
The value is set for the currently selected load (WGENerator<m>:OUTPut[:LOAD]).
If the load is changed, the value of the amplitude is adapted to this new setting.
Suffix:
<m>
.
1..2
Parameters:
<Amplitude> Range: 0.01 to 12
Increment: 0.1
*RST: 1
Default unit: V
WGENerator<m>:VOLTage:DCLevel <DCLevel>
Sets the DC level of the generated DC signal.
Suffix:
<m>
.
1..2
Parameters:
<DCLevel> Range: -5.995 to 5.995
Increment: 0.1
*RST: 0
Default unit: V
Waveform generator (option R&S RTP-B6)
