12.4 Reports
Reports document the current measurement and test results. The report contains gen-
eral information, current vertical and horizontal settings, trigger settings, active chan-
nels and all current results except for zoom and search results. A screenshot is also
included.
You can create the report manually, or automatically on defined events:
●
Press the [Camera] key.
●
Tap the "Create report" toolbar icon.
Before, add the icon to the toolbar, see also Chapter 3.3.6.2, "Configuring the tool-
bar", on page 74.
●
Action on micro button, available on active Rohde & Schwarz probes
●
Action on trigger
●
Event action at mask testing
●
Event action at limit checks
12.4.1 Report settings
Access: "Menu" menu > "Save/Recall" menu > "Save" tab > "Report"
Reports
