Column Description
Frame Type Type of the frame
Info Information about the frame
Table 13-40: Content of the Details frame table
Column Description
State Overall state of the field
Start Start time of the field
Type Type (name) of field
Numeric value The numeric value of the field
Formatted Formatted content of the field
Remote commands
Remote commands are described in Chapter 22.17.21.3, "Decode results",
on page 2089.
13.20.5 Search on decoded USBPD data
Using the search functionality, you can find various events in the decoded data. You
can find the same events that you can trigger on, and even many more, since several
event types can also be combined.
Before you can start the search, you have to configure the bus correctly and acquire
decoded data.
To search on decoded data, set the search source to "SerBus" for the configured proto-
col.
For general information on how to handle the search functionality, see Chapter 11,
"Search functions", on page 448.
If you need information on how to get started with searching USBPD data, see Chap-
ter 13.20.5.3, "Searching USBPD data", on page 860. Otherwise proceed with the
USBPD search setup.
13.20.5.1 USBPD search setup
Access: [Protocol] > "Shortcuts" tab > "Setup search"
Search
In the "Search" dialog to define the frame type in which data is to be searched.
USBPD (option R&S
RTP-K63)
