22.8.7 Probes
TRPRobe:... command are dedicated commands for the external trigger input.
● Common probe settings......................................................................................1206
● Micro button and R&S ProbeMeter..................................................................... 1209
● Passive probes....................................................................................................1213
● Active voltage probes..........................................................................................1215
● Modular probes................................................................................................... 1218
● Modular probes, deembedding........................................................................... 1221
● Predefined probes...............................................................................................1224
● Current probes.................................................................................................... 1225
● Probe attributes...................................................................................................1226
● Probe adapter R&S RT‑Z1M...............................................................................1228
22.8.7.1 Common probe settings
TRPRobe:SETup:STATe?............................................................................................. 1206
PROBe<m>:SETup:STATe?.......................................................................................... 1206
TRPRobe:SETup:TYPE?.............................................................................................. 1207
PROBe<m>:SETup:TYPE?...........................................................................................1207
TRPRobe:SETup:NAME?............................................................................................. 1207
PROBe<m>:SETup:NAME?.......................................................................................... 1207
TRPRobe:SETup:BANDwidth?...................................................................................... 1207
PROBe<m>:SETup:BANDwidth?...................................................................................1207
TRPRobe:SETup:ATTenuation[:AUTO]?.........................................................................1207
PROBe<m>:SETup:ATTenuation[:AUTO]?......................................................................1207
PROBe<m>:SETup:OFFSet:AZERo...............................................................................1208
PROBe<m>:SETup:OFFSet:USEautozero......................................................................1208
CHANnel<m>:EATScale............................................................................................... 1208
CHANnel<m>:EATTenuation......................................................................................... 1209
TRPRobe:SETup:STATe?
PROBe<m>:SETup:STATe?
Queries if the probe at the specified input channel is active (detected) or not active (not
detected). To switch the probe on, use CHANnel<m>:STATe.
Suffix:
<m>
.
1..4
Return values:
<State> DETected | NDETected
*RST: NDETected
Usage: Query only
Asynchronous command
Acquisition and setup

Rohde & Schwarz RTP Series Specifications

General

Memory Depth	Up to 2 Gsample
Input Impedance	50 Ω, 1 MΩ
Operating System	Windows 10
Channels	4
Maximum Sample Rate	20 Gsample/s
Display Type	Touchscreen
Protocols	I2C, SPI, UART, CAN, LIN, FlexRay, USB, Ethernet
Trigger Types	Edge, Pulse
Protocol Analysis	Yes
