Remote control commands
R&S
®
RTP
2123User Manual 1337.9952.02 ─ 12
EEP
Error end of packet
ESC
Escape
NULL
Null symbol
TCOD
Time code
*RST: DATA
Usage: Query only
22.17.23
PCIe (option R&S RTPK72/K73)
● Configuration.......................................................................................................2123
● Clock data recovery............................................................................................ 2126
● Digital signal processing (DSP)...........................................................................2128
● Trigger.................................................................................................................2130
● Decode results.................................................................................................... 2140
● Search settings................................................................................................... 2148
● Search results..................................................................................................... 2162
22.17.23.1 Configuration
In all BUS<m>:PCIE commands, the suffix <m> selects the serial bus.
BUS<m>:PCIE:DSCRambling....................................................................................... 2123
BUS<m>:PCIE:FIDLe...................................................................................................2124
BUS<m>:PCIE:GEN.....................................................................................................2124
BUS<m>:PCIE:LNKW.................................................................................................. 2124
BUS<m>:PCIE:LZER:SOURce......................................................................................2124
BUS<m>:PCIE:LONE:SOURce..................................................................................... 2125
BUS<m>:PCIE:LTWO:SOURce.....................................................................................2125
BUS<m>:PCIE:LTHRee:SOURce.................................................................................. 2125
BUS<m>:PCIE:LZER:THRHigh..................................................................................... 2125
BUS<m>:PCIE:LONE:THRHigh.....................................................................................2125
BUS<m>:PCIE:LTWO:THRHigh.................................................................................... 2125
BUS<m>:PCIE:LTHRee:THRHigh..................................................................................2125
BUS<m>:PCIE:LZER:THRLow......................................................................................2125
BUS<m>:PCIE:LONE:THRLow..................................................................................... 2125
BUS<m>:PCIE:LTWO:THRLow..................................................................................... 2125
BUS<m>:PCIE:LTHRee:THRLow.................................................................................. 2125
BUS<m>:PCIE:SMLanes.............................................................................................. 2125
BUS<m>:PCIE:DSCRambling <Active>
Enables descrambling of the data.
