Data and file management
R&S
®
RTP
478User Manual 1337.9952.02 ─ 12
1. On the toolbar, tap the "Saveset with preview " icon.
A window opens and shows the screenshot of the first measurement configuration
that is stored in the default directory.
2. Select if you want to display a "SaveSets" file or a reference waveform ("Ref
Wfm").
3. Find the required file using one of the following methods:
● Tap the "Next" icon on the right or the "Previous" icon on the left to scroll the
savesets of the directory.
The file name is shown on the top, and the screenshot helps to identify the set-
tings.
● If the saveset was stored in another directory, use the path buttons at the bot-
tom, or tap "Open" to open the required directory.
● Tap "Sort by" to sort the files according to the "Last modified" date or the "File-
name".
● Specify a "Filter" name to show only the files containing the filter string.
4. Tap "Load" in the upper left corner to recall the settings of the selected file.
12.1.5 Saving and loading settings
Settings can be stored in a file with user-defined name and location, or in a quick save-
set. The settings in a saveset can be saved and retrieved quickly at the touch of a but-
ton, so savesets are ideal for frequently used measurements.
For details on save/recall instrument settings and associated remote commands, see
Chapter 12.1.1, "Savesets", on page 473.
Save and recall user settings
