22.9.3 Glitch trigger
TRIGger<m>:GLITch:POLarity.......................................................................................1259
TRIGger<m>:GLITch:RANGe........................................................................................ 1259
TRIGger<m>:GLITch:WIDTh......................................................................................... 1259
TRIGger<m>:GLITch:POLarity <Polarity>
Defines the polarity of a pulse, that is the direction of the first pulse slope.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<Polarity> POSitive | NEGative | EITHer
See Chapter 22.4.4, "Polarity parameter", on page 1147.
*RST: POSitive
Usage: Asynchronous command
TRIGger<m>:GLITch:RANGe <RangeMode>
Selects which glitches are identified: shorter or longer than the width specified using
TRIGger<m>:GLITch:WIDTh.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<RangeMode> SHORter | LONGer
SHORter
Glitches shorter than the specified width are identified.
LONGer
Glitches longer than the specified width are identified.
*RST: SHORter
Usage: Asynchronous command
TRIGger<m>:GLITch:WIDTh <Width>
Sets the length of a glitch. The instrument triggers on pulses shorter or longer than this
value, depnding on the TRIGger<m>:GLITch:RANGe command.
You need to know the expected pulse widths of the circuit to set the glitch width cor-
rectly.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
