Remote control commands
R&S
®
RTP
1508User Manual 1337.9952.02 ─ 12
CURSor<m>:THReshold <Value>
Defines an absolute threshold as an additional condition for the peak search. Only
peaks that exceed the threshold are detected.
Suffix:
<m>
.
The suffix is irrelevant.
Parameters:
<Value> Threshold in dBm
Usage: Asynchronous command
Firmware/software: Version 2.70
22.15.15
Search gate settings
SEARch:GATE[:STATe].................................................................................................1508
SEARch:GATE:MODE..................................................................................................1508
SEARch:GATE:SHOW..................................................................................................1509
SEARch:GATE:ABSolute:STARt....................................................................................1509
SEARch:GATE:ABSolute:STOP.................................................................................... 1509
SEARch:GATE:RELative:STARt.................................................................................... 1509
SEARch:GATE:RELative:STOP.....................................................................................1510
SEARch:GATE:ZCOupling............................................................................................ 1510
SEARch:GATE:ZDIagram............................................................................................. 1510
SEARch:GATE[:STATe] <SearchName>,<State>
SEARch:GATE[:STATe]? <SearchName>
Performs the search only on the defined gate area of the source waveform.
Parameters:
<State> ON | OFF
*RST: OFF
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
SEARch:GATE:MODE <SearchName>,<Mode>
SEARch:GATE:MODE? <SearchName>
Defines whether the gate settings are configured using absolute or relative values.
Parameters:
<Mode> ABS | REL
*RST: ABS
Parameters for setting and query:
<SearchName> Search definition
