Remote control commands
R&S
®
RTP
2217User Manual 1337.9952.02 ─ 12
Parameters:
<WidthDelta> Range: 0 to 432
Increment: 500E-12
*RST: 0
Default unit: s
Usage: Asynchronous command
22.18.4.8 Serial pattern trigger
See also:
TRIGger<m>:PARallel:SPATtern:CSOurce[:VALue] on page 2210
TRIGger<m>:PARallel:SPATtern:EXPRession[:DEFine] on page 2210
TRIGger<m>:PARallel:SPATtern:CSOurce:EDGE <ClockEdge>
Sets the edge of the clock signal. The bit value is determined at the crossing of the
clock edge and the logical threshold.
Parameters:
<ClockEdge> POSitive | NEGative | EITHer
*RST: POSitive
Usage: Asynchronous command
TRIGger<m>:PARallel:SPATtern:PATTern <Pattern>
Defines the serial bit string on which to trigger.
Parameters:
<Pattern> Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The bit value X (don't care) is not
allowed.
Usage: Asynchronous command
22.18.5 MSO data
To export data of digital channels and parallel buses to file, use the following com-
mands:
EXPort:WAVeform:SOURce on page 1527
EXPort:WAVeform:NAME on page 1530
EXPort:WAVeform:SAVE on page 1530
The remote data transfer from the instrument to the controlling computer is performed
using the following commands:
Mixed signal option (MSO, R&S
RTP-B1)
