Parameters:
<Width> Range: 100E-12 to 10000
Increment: 100E-6
*RST: 1E-9
Default unit: s
Usage: Asynchronous command
22.9.4 Width trigger
TRIGger<m>:WIDTh:POLarity.......................................................................................1260
TRIGger<m>:WIDTh:RANGe........................................................................................ 1260
TRIGger<m>:WIDTh:WIDTh......................................................................................... 1261
TRIGger<m>:WIDTh:DELTa..........................................................................................1261
TRIGger<m>:WIDTh:POLarity <Polarity>
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<Polarity> POSitive | NEGative
See Chapter 22.4.4, "Polarity parameter", on page 1147.
*RST: POSitive
Usage: Asynchronous command
TRIGger<m>:WIDTh:RANGe <RangeMode>
Defines how the range of a pulse width is defined in relation to the width and delta
specified using TRIGger<m>:WIDTh:WIDTh and TRIGger<m>:WIDTh:DELTa,
respectively.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<RangeMode> WITHin | OUTSide | SHORter | LONGer
WITHin
Triggers on pulses inside a given range. The range is defined by
the width ±delta.
OUTSide
Triggers on pulses outside a given range. The range is defined
by the width ±delta.
SHORter
Triggers on pulses shorter than the given width.
Trigger
