Search functions
R&S
®
RTP
462User Manual 1337.9952.02 ─ 12
Pattern
Pattern search settings are the same as for the pattern trigger.
See also "Pattern" on page 230.
Remote command:
SEARch:TRIGger:PATTern:A[:ENABle] on page 1501
SEARch:TRIGger:PATTern:A:LOGic on page 1501
SEARch:TRIGger:PATTern:AB:LOGic on page 1502
SEARch:TRIGger:PATTern:ABCD:LOGic on page 1502
Timing condition: Mode, Range, Time, Width, ±Delta
Additional time limitation to the pattern, see "Additional settings: Timing" on page 232.
Remote command:
SEARch:TRIGger:PATTern:MODE on page 1502
SEARch:TRIGger:PATTern:TIMeout:MODE on page 1503
SEARch:TRIGger:PATTern:TIMeout[:TIME] on page 1503
SEARch:TRIGger:PATTern:WIDTh:RANGe on page 1503
SEARch:TRIGger:PATTern:WIDTh[:WIDTh] on page 1504
SEARch:TRIGger:PATTern:WIDTh:DELTa on page 1504
11.2.3 Frequency marker search
When you start a search on a spectrum, a frequency marker search is performed to
detect peaks in a spectrum. You can define which peaks the instrument finds by defin-
ing the noise reject settings.
Threshold
See "Threshold" on page 329.
Peak excursion
See "Peak excursion" on page 329.
11.2.4 Configuring the search setup
There are several ways to create a search:
●
Creating a simple default search using the toolbar icon. This method is not availa-
ble for search on serial buses.
●
Setting up a search using the dialog box.
To perform a simple search
1. If more than one waveform is in the diagram, select the waveform to be searched
for by tapping it in the diagram.
2. Select the "Search" icon on the toolbar.
Search setup
