Rohde & Schwarz RTP Series User Manual

Maintenance and support
R&S
®
RTP
2317User Manual 1337.9952.02 ─ 12
23 Maintenance and support
The instrument does not need periodic maintenance. Only the cleaning of the instru-
ment is essential.
To protect the front panel and to transport the instrument to another workplace safely
and easily, various accessories are provided. Refer to the data sheet for available cov-
ers and cases and their order numbers.
The adjustment of the OCXO oscillator is described in the service manual.
23.1 Cleaning
How to clean the product is described in "Cleaning the product" on page 31.
Do not use any liquids for cleaning. Cleaning agents, solvents (thinners, acetone),
acids and bases can damage the front panel labeling, plastic parts and display.
23.2 Power cables for R&S RTP
Rohde & Schwarz provides power cables with different properties for use in different
countries.
Table 23-1: List of power cables
Material No. Material name Recommended for
3586.6406.00 Power cable 2.5 m, CEE 7/7 - C19 Europe
3630.6882.00 Power cable 2.5 m, NEMA 5/15 - C19 USA
3640.3834.00 Power cable 2.5 m, SAA3 - C19 China, Australia
3629.0032.00 Power cord 2.5 m, BS1363 - C19 UK
3639.9132.00 Power cable 2.5 m - C19-YP12 Japan
3630.6899.00 Power cable 2.5 m, ZA3 - C19 South Afrika, India
3630.6901.00 Power cable 2.5 m, 12G - C19 Switzerland
3630.6924.00 Power cable 2.5 m, BR/3/20 - C19 Brazil
3658.0566.00 Power cable 2.5 m, IL/3 – C19 Israel
Power cables for R&S RTP

Rohde & Schwarz RTP Series Specifications

General

Memory Depth	Up to 2 Gsample
Input Impedance	50 Ω, 1 MΩ
Operating System	Windows 10
Channels	4
Maximum Sample Rate	20 Gsample/s
Display Type	Touchscreen
Protocols	I2C, SPI, UART, CAN, LIN, FlexRay, USB, Ethernet
Trigger Types	Edge, Pulse
Protocol Analysis	Yes
