Remote control commands
R&S
®
RTP
2169User Manual 1337.9952.02 ─ 12
22.17.24 DDR (option R&S RTP-K91/K93)
● Configuration.......................................................................................................2169
● Decode results.................................................................................................... 2171
● Search settings................................................................................................... 2175
● Search results..................................................................................................... 2180
● Eye diagram analysis..........................................................................................2184
22.17.24.1 Configuration
In all BUS<m>:DDR commands, the suffix <m> selects the serial bus.
BUS<m>:DDR:STANdard............................................................................................. 2169
BUS<m>:DDR:DATA:HYSTeresis.................................................................................. 2169
BUS<m>:DDR:DATA:SOURce...................................................................................... 2170
BUS<m>:DDR:DATA:THReshold................................................................................... 2170
BUS<m>:DDR:STRBe:HYSTeresis................................................................................ 2170
BUS<m>:DDR:STRBe:SOURce.................................................................................... 2170
BUS<m>:DDR:STRBe:THReshold.................................................................................2171
BUS<m>:DDR:BITRate................................................................................................ 2171
BUS<m>:DDR:STANdard <Standard>
Selects the DDR standard.
Suffix:
<m>
.
1..4
Parameters:
<Standard> DDR3 | | DDR4
DDR3: requires option R&S RTP-K91.
DDR4: requires option R&S RTP-K93.
*RST: DDR3
Usage: Asynchronous command
BUS<m>:DDR:DATA:HYSTeresis <DataHysteresis>
Sets a value for the hysteresis of the data.
Suffix:
<m>
.
1..4
Parameters:
<DataHysteresis> Range: 0 to 10
Increment: 0.01
*RST: 0.15
Default unit: V
Usage: Asynchronous command
