ADVJitter<m>:DCOMposition:NVERtical <MaxNumber>
Sets the maximum number of periodic components in the vertical direction that are
considered for the measurement. If the actual number of periodic components is higher
than the set value, they are considered for the random jitter component.
Suffix:
<m>
.
1..2
Parameters:
<MaxNumber> Range: 0 to 10
Increment: 1
*RST: 5
ADVJitter<m>:DCOMposition:ENOBu <State>
Suffix:
<m>
.
1..2
Parameters:
<State> ON | OFF
*RST: OFF
22.22.3 Clock data recovery (software-based, option R&S RTP-K12)
CDR:SOFTware<m>:ALGorithm....................................................................................2286
CDR:SOFTware<m>:SERStandard................................................................................2287
CDR:SOFTware<m>:ESBRate:SOURce........................................................................ 2288
CDR:SOFTware<m>:ESBRate:BREStimate....................................................................2288
CDR:SOFTware<m>:ESBRate:CONTinuous...................................................................2288
CDR:SOFTware<m>:BITRate........................................................................................2288
CDR:SOFTware<m>:ESLope........................................................................................2289
CDR:SOFTware<m>:SYNC.......................................................................................... 2289
CDR:SOFTware<m>:RESults........................................................................................2289
CDR:SOFTware<m>:PLL:ORDer...................................................................................2290
CDR:SOFTware<m>:PLL:BWIDth..................................................................................2290
CDR:SOFTware<m>:PLL:RELBwidth.............................................................................2290
CDR:SOFTware<m>:PLL:DAMPing............................................................................... 2291
CDR:SOFTware<m>:REVLockpll...................................................................................2291
CDR:SOFTware<m>:SAMTime..................................................................................... 2291
CDR:SOFTware<m>:ALGorithm <Algorithm>
Sets the software algorithm that is used for clock data recovery.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Parameters:
<Algorithm> CFRequency | PLL | FF | PLLStart
