Remote control commands
R&S
®
RTP
2233User Manual 1337.9952.02 ─ 12
Suffix:
<m>
.
1..2
Parameters:
<WaveformSource> ARBitrary | SCOPe
ARBitrary
Enables you to load an existing arbitrary file.
SCOPe
Enables you to load a scope waveform.
*RST: ARBitrary
WGENerator<m>:ARBGen:RUNSingle
Executes a single period of the arbitrary signal generator, for WGENerator<m>:
ARBGen:RUNMode SINGle.
Suffix:
<m>
.
1..2
Usage: Event
22.19.2 Pattern generator setup
PGENerator:BITRate....................................................................................................2233
PGENerator:ENABle.................................................................................................... 2233
PGENerator:FILE:OPEN...............................................................................................2234
PGENerator:FILE[:NAME].............................................................................................2234
PGENerator:HLEVel.....................................................................................................2234
PGENerator:PRESet.................................................................................................... 2234
PGENerator:RUNMode.................................................................................................2234
PGENerator:RUNSingle................................................................................................2234
PGENerator:BITRate <BitRate>
Sets the number of transmitted bits per second for the pattern generator.
Parameters:
<BitRate> Range: 1 to 40E+6
Increment: 10
*RST: 1E+6
Default unit: bps
PGENerator:ENABle <State>
Enables the pattern generator and outputs the waveform.
Parameters:
<State> ON | OFF
Waveform generator (option R&S RTP-B6)
