Rohde & Schwarz RTP Series - Waveform Data

Remote control commands
R&S
®
RTP
1455User Manual 1337.9952.02 ─ 12
CALCulate:MATH<m>:FFT:COUPled:WITH<1..8> <MathIndex>
Copies the current FFT settings of the selected math waveform (m) to the other
selected math waveform (m2), and couples the two waveforms. This can be repeated
for all math waveforms.
If any FFT setting for any of the coupled spectrums is changed, it is changed for all
coupled spectrums.
Suffix:
<m>
.
1..8
FFT waveforms to be coupled. <m>, <m2> must be active and
distinct.
Parameters:
<MathIndex> ON | OFF
*RST: OFF
Example: Prerequisite: FFt waveforms M1 and M2 are active.
CALC:MATH1:FFT:COUP:WITH2 ON
Couples the math waveforms M1 and M2.
Usage: Asynchronous command
22.13.2 Waveform data
CALCulate:MATH<m>:DATA:STYPe?............................................................................ 1455
CALCulate:MATH<m>:DATA:HEADer?...........................................................................1456
CALCulate:MATH<m>:DATA[:VALues]?..........................................................................1456
CALCulate:MATH<m>:DATA:STYPe?
Returns the signal type of the source of the math waveform.
Suffix:
<m>
.
1..8
Selects the math waveform.
Return values:
<SignalType> SOUR | SPEC | CORR | MEAS | NONE
SOURce = normal signal
SPECtrum = FFT spectrum, specific math signal
CORRelation = correlated signal, specific math signal
MEAsurement = result of a measurement
NONE = undefined
Usage: Query only
Asynchronous command
Spectrum analysis
