Remote control commands
R&S
®
RTP
2122User Manual 1337.9952.02 ─ 12
OK
The frame is valid
PARity
Parity error
ESC
Escape Error
AMB
Ambiguous
INComplete
The frame is incomplete
*RST: OK
Usage: Query only
SEARch:RESult:SWIRe:FRAMe<m>:STOP?
<SearchName>
Returns the end time for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<Stop> Range: -100E+24 to 100E+24
Increment: 100E-12
*RST: 0
Default unit: s
Usage: Query only
SEARch:RESult:SWIRe:FRAMe<m>:TYPE? <SearchName>
Returns the type of frame for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<Type> DATA | FCT | EOP | EEP | ESC | NULL | TCOD
DATA
Data frame
FCT
Flow control token
EOP
End of packet
Protocols
