Remote control commands
R&S
®
RTP
1506User Manual 1337.9952.02 ─ 12
Parameters for setting and query:
<SearchName> String with the name of the search
Usage: Asynchronous command
SEARch:TRIGger:STATe:A[:ENABle] <Searchname>, <State>
SEARch:TRIGger:STATe:A[:ENABle]? <Searchname>
SEARch:TRIGger:STATe:B[:ENABle] <Searchname>, <State>
SEARch:TRIGger:STATe:B[:ENABle]? <Searchname>
SEARch:TRIGger:STATe:C[:ENABle] <Searchname>, <State>
SEARch:TRIGger:STATe:C[:ENABle]? <Searchname>
SEARch:TRIGger:STATe:D[:ENABle] <Searchname>, <State>
SEARch:TRIGger:STATe:D[:ENABle]? <Searchname>
Enables the channel to be considered in the state search. You can enable all channel
signals except for the trigger source.
●
A[:ENABle]: CH1
●
B[:ENABle]: CH2
●
C[:ENABle]: CH3
●
D[:ENABle]: CH4
Digital channels are not available.
Parameters:
<State> ON | OFF
Parameters for setting and query:
<Searchname> String with the name of the search
Usage: Asynchronous command
SEARch:TRIGger:STATe:A:LOGic <Searchname>, <Operator>
SEARch:TRIGger:STATe:A:LOGic? <Searchname>
SEARch:TRIGger:STATe:B:LOGic <Searchname>, <Operator>
SEARch:TRIGger:STATe:B:LOGic? <Searchname>
SEARch:TRIGger:STATe:C:LOGic <Searchname>, <Operator>
SEARch:TRIGger:STATe:C:LOGic? <Searchname>
SEARch:TRIGger:STATe:D:LOGic <Searchname>, <Operator>
SEARch:TRIGger:STATe:D:LOGic? <Searchname>
Defines the logic for the indicated channel:
●
A: CH1
●
B: CH2
●
C: CH3
●
D: CH4
Parameters:
<Operator> DIRect | HIGH | NOT | LOW
DIRect
Input value remains unchanged
Search

Rohde & Schwarz RTP Series Specifications

General

Memory Depth	Up to 2 Gsample
Input Impedance	50 Ω, 1 MΩ
Operating System	Windows 10
Channels	4
Maximum Sample Rate	20 Gsample/s
Display Type	Touchscreen
Protocols	I2C, SPI, UART, CAN, LIN, FlexRay, USB, Ethernet
Trigger Types	Edge, Pulse
Protocol Analysis	Yes
