BUS<m>:USB:DMINus:SOURce <SourceDminus>
Selects the source for the D- data signal (in USB low speed and USB full speed proto-
col, only).
Suffix:
<m>
.
1..4
Parameters:
<SourceDminus> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
*RST: C2W1
Usage: Asynchronous command
BUS<m>:USB:DIFFerential:SOURce
<SrcDiff>
Selects the source for the differential signal in the USB high speed protocol.
Suffix:
<m>
.
1..4
Parameters:
<SrcDiff> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
*RST: C1W1
Usage: Asynchronous command
BUS<m>:USB:DPLus:THReshold <ThresholdDplus>
Defines the threshold level for the D+ data signal (in USB low speed and USB full
speed protocol, only).
Suffix:
<m>
.
1..4
Parameters:
<ThresholdDplus> Range: -5 to 5
Increment: 0.01
*RST: 1.55
Default unit: V
BUS<m>:USB:DMINus:THReshold <ThresholdDminus>
Defines the threshold level for the D- data signal (in USB low speed and USB full
speed protocol, only).
Suffix:
<m>
.
1..4
