Rohde & Schwarz RTP Series - Page 2021

Remote control commands
R&S
®
RTP
2021User Manual 1337.9952.02 ─ 12
Return values:
<CRC> Range: 0 to 65535
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:USB:PACKet<n>:DATA?
Returns the payload data from the packet with the selected packet number (for the
selected serial bus).
Suffix:
<m>
.
1..4
<n> *
Parameters:
<Data> Comma-separated sequence of integer values (N, D1, D2,…,
DN). N is the number of bytes in the packet. and D1…DN are
the values of the bytes.
Example:
BUS:USB:PACKet4:DATA?
<-- 6,18,52,86,120,154,188
Usage: Query only
BUS<m>:USB:PACKet<n>:ENDPoint?
Returns the endpoint for the selected serial bus and packet number.
Suffix:
<m>
.
1..4
<n> *
Return values:
<Endp> Range: 0 to 15
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:USB:PACKet<n>:ET?
Returns the endpoint type (ET) for the selected serial bus and packet number.
Suffix:
<m>
.
1..4
<n> *
Protocols
